EB5100 SERIES low profile LED beacon with clear lens

EB5100 SERIES low profile LED beacon with clear lens

SKU:EB5101CA

Regular price £71.68 GBP
Regular price Sale price £71.68 GBP
Sale Sold out
Shipping calculated at checkout.

Ecco

Quantity
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR
EMPTY DOM REMOVE PROTECTOR

INSTALLATION & CARE

To preserve the quality of your lights, do not utilise a pressure washer on a high setting.

The use of harsh cleaning chemicals can detrimentally effect the appearance and life of the product. Use warm soapy water and a wash brush or clean sponge to thoroughly clean front and back and rising to remove all soap.

With today’s high-quality lighting offering excellent dust and water sealing, lamp failures are rare. One common cause is water tracking through unsealed electrical connections, causing the copper core to blacken. Using waterproof plugs and sockets (superseals or Deutsch connectors) and adhesive heat-shrink sleeving and terminals can prevent this issue.

ADDITIONAL INFORMATION

SHIPPING

Orders placed before 12:00
Processed & shipped the same day unless otherwise stated.

Orders placed after 12:00
Processed & shipped the next working day.

Orders placed after 12:00 on a Friday.
Processed & shipped the following Monday.

Orders are shipped Monday-Friday only.

EMPTY DOM REMOVE PROTECTOR
View full details

Some website images have been AI enhanced for improved visual presentation only. Product specifications, appearance, and performance remain unchanged.

Technical Specifications

Specification Details
Part Number EB5101CA
Flash Patterns 12
Colours Amber
Voltage 10-30V
Approvals R10 : R65 : CISPR 25 Class 3
IP Rating IP69K
Mounting Single Bolt
Additional Features 5 Year warranty
Lens Material Polycarbonate
Dimensions 63 x 149mm

The Low Profile R65 LED Warning Beacon is engineered for demanding commercial and industrial applications where maximum visibility, durability and reliability are essential. Producing a powerful 360° warning signal, it utilises high-output LEDs and advanced solid-state technology to deliver maintenance-free performance and an exceptionally long service life.

Designed to meet ECE R65 Class 1 requirements, the amber LED versions (available with amber or clear lenses) produce a highly effective simulated rotating warning pattern. Multiple flash patterns and synchronisation capability allow several beacons to operate together for enhanced vehicle visibility, while improved CISPR 25 Class 3 EMC performance ensures dependable operation alongside today's sophisticated vehicle electronics.

Built to withstand harsh working environments, this compact low-profile beacon has been rigorously tested to ECCOstandards and OEM specifications. Its robust construction is specifically designed to resist excessive vibration, extending product life on commercial vehicles, plant machinery and specialist equipment. Available with four standard mounting options to suit a wide range of installations, every beacon is backed by a comprehensive five-year no-hassle warrantyfor complete peace of mind.
