Adhesive-Lined Heat Shrink Mini Reels – 3:1 sharing ratio
Adhesive-Lined Heat Shrink Mini Reels – 3:1 sharing ratio
SKU:CHSMR31-3.2
C-Tie
Couldn't load pickup availability
DESCRIPTION
DESCRIPTION
CHS31 is a dual-wall adhesive-lined heat shrink tubing manufactured from flame retardant cross-linked polyolefin. This tubing may be used in a wide variety of electrical applications and provides excellent waterproofing and moisture protection. Its high shrink ratio makes it ideal for sealing irregular shapes. From stock in black only.
Mini Reel length per size :
3.2mm x 10m.
4.8mm x 5m.
6.4mm x 5m.
9.5mm x 5m.
12.7mm x 5m.
19.1mm x 4m.
25.4mm x 3m.
SPECIFICATION
SPECIFICATION
Technical Specifications
Material
Polyolefin (With Hot-Melt Adhesive)
Shrink Ratio
3:1
Working Temperature
-55°C to +125°C
Shrink Temperature
+90°C
Dielectric Voltage Withstand
2500V, 60 Seconds, No Breakdown
RoHS Compliant
Yes
Zero Halogen
Yes
Flammability
VW-1
INSTALLATION & CARE
INSTALLATION & CARE
To preserve the quality of your lights, do not utilise a pressure washer on a high setting.
The use of harsh cleaning chemicals can detrimentally effect the appearance and life of the product. Use warm soapy water and a wash brush or clean sponge to thoroughly clean front and back and rising to remove all soap.
With today’s high-quality lighting offering excellent dust and water sealing, lamp failures are rare. One common cause is water tracking through unsealed electrical connections, causing the copper core to blacken. Using waterproof plugs and sockets (superseals or Deutsch connectors) and adhesive heat-shrink sleeving and terminals can prevent this issue.
